Motor work

[CrawlinClodKiller]

I am in the process of doing some extreme motor work and had an idea. If eveyone could post pics they can find of p&p jobs and any other custom motor work, any labeled engineering type drawing of cranks, pistons, sleeves, etc I want to make an engine writeup about all the working of the motor and explain the changes that are made when p&p jobs are done. This will help myself as well as everyone else to understand their motors and what can be done to them. thanks alot

Here are the ones found so far:

Nitro Star 25
https://www.hpisavageforum.com/forums/showthread.php?t=2650&page=3
https://www.hpisavageforum.com/forums/showthread.php?t=2933



[Wannus]

Check this out..
https://www.hpisavageforum.com/forums/showthread.php?t=2650&page=3
There are 4 .pdf files how to p&p the nitrostar.25 engine.



[CrawlinClodKiller]

Cool thanks. I already have those but this is the type of stuff I am looking for, as well as people's own or just straight pics from sites



[Fx]

https://www.hpisavageforum.com/forums/showthread.php?t=2933
Scroll down some should be informative.



[CrawlinClodKiller]

Thank you for that. I read that one too, but I want them all linked into this post to make them easier to find. Once there are a few I will combine them all into my first post.



[Fx]

I know mondragon did some porting and polishing. He posted it a while back, I'll look around.



[CrawlinClodKiller]

sneek peek at my motor in work
