HPI Savage 25 Manuals



HPI Savage 25 Manual (model #: 12829): HPI Savage 25 Manual (mirror)


Find and buy parts at: HPI Savage Truck Parts.

HPI Savage 25 Parts Listing



Chassis Components

#73917 - MAIN CHASSIS 2.5mm
#85059 - BUMPER SET/LONG BODY MOUNT SET
#85060 - SKID PLATE/BODY MOUNT/SHOCK
#85061 - RADIO BOX SET
#86062 - JOINT POST 4x7x74mm (2pcs)
#86063 - ENGINE MOUNT BRACE 7x7x74mm
#86067 - BULKHEAD LOWER PLATE 2.5mm
#86068 - UPPER ARM BRACE 4x54x3mm
#86070 - LOWER ARM BRACE 4x54x3mm
#86129 - ROLL BAR

Drivetrain

#72130 - STAINLESS STEEL SLIPPER PLATE
#72131 - SLIPPER CLUTCH PAD (2pcs)
#76914 - TRANSMISSION GEAR 44 TOOTH
#76929 - TRANSMISSION GEAR 39 TOOTH
#76939 - SPUR GEAR 49 TOOTH (1M)
#85044 - DIFF CASE SET
#85045 - GEAR BOX/BULKHEAD SET
#85046 - CENTER GEAR BOX
#86030 - BEVEL GEAR 43 TOOTH (1M)
#86031 - BEVEL GEAR 13 TOOTH (1M)
#86032 - BEVEL GEAR SET (GEAR DIFF)
#86056 - DOGBONE 8x84mm (BLACK)
#86057 - DOGBONE 8x78mm (BLACK)
#86058 - DOGBONE 9x123mm (BLACK/2pcs)
#86064 - DIFF SHAFT 14x34mm
#86065 - AXLE 8x9x44mm (BLACK/2pcs)
#86066 - HEX WHEEL HUB 14mm
#86081 - GEAR SHAFT 6x12x78mm (BLACK)
#86082 - CUP JOINT 6x13x20mm
#86083 - CUP JOINT 8x19mm (BLACK/2pcs)
#86084 - DRIVE GEAR 32 TOOTH (1M)
#86087 - CLUTCH GEAR HOLDER WITH ONE-WAY
#86088 - IDLER SHAFT 6x8x45mm (BLACK)
#86089 - DRIVE SHAFT 6x70mm (BLACK)
#86091 - CLUTCH HOLDER SET
#86092 - BRAKE CAM/PISTON SET
#86094 - SCREW SHAFT M4x2.5x12mm
#86095 - SCREW SHAFT M5x3x18mm
#86097 - DRIVE GEAR 18-23 TOOTH (1M)
#86098 - IDLER GEAR 29 TOOTH (1M)
#86127 - GEAR DIFF SET 43T (ASSEMBLED)
#86128 - 2 SPEED MAINTENANCE KIT
#86130 - SLIPPER CLUTCH HUB
#86132 - AXLE 8x9x44mm
#86318 - BRAKE HUB (ALLOY CAST/SILVER)
#87041 - RUBBER CAP FOR GEAR BOX (2pcs)
#87042 - SPRING 4.9x8x7mm/WASHER 4
#87053 - BRAKE DISK/PLATE SET
#B072 - METAL BUSHING 5x11x4mm (6pcs)

Suspension and Steering

#6749 - SHOCK SPRING 14.4x117x1.4mm 26
#6811 - O-RING 6x9.5x2mm (BLACK/8pcs)
#6816 - SILICONE O-RING S10 (6pcs)
#6819 - SILICONE O-RING P-3 (RED/5pcs)
#6899 - O-RING 5x8x1.5mm (6pcs)
#85047 - SUSPENSION ARM SET
#85048 - UPRIGHT SET
#85049 - SHOCK BODY SET (2 SHOCKS)
#85050 - SHOCK PARTS/ROD END SET (2
#85051 - SERVO SAVER/ FUEL TANK HOLDER
#86055 - SHOCK SHAFT 3x86mm
#86059 - BALL 6.8x7.3x3mm (BLACK/4pcs)
#86071 - FLANGE SHAFT 4x62mm
#86072 - THREADED SHAFT M4x70mm
#86073 - SHAFT 4x78mm (SILVER/2pcs)
#86074 - SHAFT 4x46mm (SILVER/2pcs)
#86090 - STEERING CRANK POST 6x49mm
#86319 - STEERING POST 12x47mm (PURPLE)
#87056 - SPORT SHOCK SET 104-162mm
#87058 - RUBBER TUBE 3x8x10mm
#87197 - CAM TYPE SERVO SAVER/THROTTLE

Savage 25 Engine and Engine Parts

#1406 - NITRO STAR S-25 ENGINE WITH
#1430 - ONE WAY BEARING FOR PULLSTART
#1503 - GLOW PLUG MEDIUM COLD R4
#86060 - ENGINE MOUNT
#86061 - EXHAUST HEADER (REAR EXHAUST)
#86069 - ENGINE PLATE 2.5mm (PURPLE)
#86076 - PILOT NUT 1/4-28x8.5mm (BLACK)
#86077 - COLLET 7x6.5mm (BRASS/2pcs)
#86101 - LINKAGE ROD SET
#86110 - TUNED PIPE (COMPOSITE
#86271 - FLYWHEEL 34mm (3 PIN)
#87040 - SILICONE EXHAUST COUPLING
#87044 - AIR CLEANER 35x35mm
#87049 - SHAPED EXHAUST GASKET (21
#87054 - EXHAUST MANIFOLD SPRING 4
#87110 - HPI ROTO START SYSTEM
#87112 - CASE FOR MOTOR UNIT
#87113 - BATTERY LID FOR MOTOR UNIT
#87115 - MOTOR AND SWITCH SET WITH
#87116 - STARTER SHAFT WITH O-RING
#87117 - BACK PLATE UNIT FOR NITRO STAR
#87118 - GEAR SET FOR BACK PLATE UNIT
#87149 - RACING FUEL TANK (160cc/NO
#87151 - PTFE CLUTCH SHOE/SPRING SET
#87153 - 3 PIECE CLUTCH SET
#a990 - HEAVY-DUTY CLUTCH BELL 15 TOOTH
#a993 - HEAVY-DUTY CLUTCH BELL 18 TOOTH

Electronics

#80551 - HPI TF-4 TRANSMITTER without
#80555 - HPI RF-2 RECEIVER without
#80560 - HPI SF-2 SERVO (HIGH TORQUE/6
#80566 - ANTENNA FOR TRANSMITTER
#80575 - RECEIVER SWITCH
#80576 - RECEIVER BATTERY CASE
#z150 - ANTENNA PIPE SET

Hardware

#6122 - BODY PIN
#6123 - BODY PIN
#6163 - SERVO TAPE 20x100mm (10pcs)
#86121 - WASHER 5x10x3mm (BRASS/4pcs)
#b021 - BALL BEARING 5x10x4mm (2pcs)
#b023 - BALL BEARING 6x13x5mm (2pcs)
#b032 - BALL BEARING 10x16x5mm (2pcs)
#b085 - BALL BEARING 8x16x5mm (2pcs)
#z224 - WASHER 3x8mm (10pcs)
#z235 - C CLIP 20mm (4pcs)
#z240 - C CLIP 8mm (4pcs)
#z243 - E CLIP E3mm (10pcs)
#z245 - E CLIP E5mm (10pcs)
#z260 - PIN 2.5x12mm (12pcs)
#z282 - STEP SCREW M3x14mm (4pcs)
#z286 - STEP SCREW M3x20mm (6pcs)
#z288 - STEP SCREW M4x20mm (4pcs)
#z303 - CAP HEAD SCREW M3x42mm (6pcs)
#z421 - CAP HEAD SCREW M2.6x8mm (12pcs)
#z423 - CAP HEAD SCREW M2.6x12mm
#z463 - TP. FLAT HEAD SCREW M2x10mm
#z481 - TP. BINDER HEAD SCREW M2.6x8mm
#z488 - TP. FLANGED SCREW M2.6x12mm
#z517 - BINDER HEAD SCREW M3x8mm
#z520 - BINDER HEAD SCREW M3x18mm
#z526 - FLAT HEAD SCREW M3x8mm (6pcs)
#z530 - FLAT HEAD SCREW M3x18mm (6pcs)
#z544 - CAP HEAD SCREW M3x12mm (6pcs)
#z547 - CAP HEAD SCREW M3x20mm (6pcs)
#z561 - TP. FLANGED SCREW M3x10mm
#z567 - TP. BINDER HEAD SCREW M3x10mm
#z569 - TP. BINDER HEAD SCREW M3x15mm
#z578 - TP. FLAT HEAD SCREW M3x12mm
#z581 - TP. FLAT HEAD SCREW M3x18mm
#z613 - BINDER HEAD SCREW M4x10mm
#z632 - TP. BINDER HEAD SCREW M4x10mm
#z634 - TP. BINDER HEAD SCREW M4x15mm
#z644 - TP. FLAT HEAD SCREW M4x15mm
#z661 - LOCK NUT M2.6 (4pcs)
#z663 - LOCK NUT M3 (6pcs)
#z682 - FLANGED LOCK NUT M5
#Z683 - FLANGED LOCK NUT M5
#z684 - FLANGED LOCK NUT M4 (4pcs)
#z685 - WASHER 2.7x6.7x0.5mm (10pcs)
#z694 - WASHER M5x10x0.5mm (10pcs)
#z700 - SET SCREW M3x3mm (6pcs)
#z721 - SET SCREW M4x4mm (4pcs)
#z792 - CAP HEAD SCREW M4x8mm (6pcs)
#z897 - WASHER 12x18x0.2mm (6pcs)

HPI Savage 25 Body and body accessories

#7758 - NITRO GT-1 TRUCK PAINTED BODY

Wheels and Tires

#3007 - GT5 WHEEL CHROME (83x56mm/2pcs)
#4464 - GT TIRES S COMPOUND

Oils and Chemicals

#z159 - THREAD LOCK
#z160 - GREASE (#10000)

Fuel and fuel accessories

#50474 - SILICONE TUBE 2x5x300mm

Tools

#z901 - ALLEN WRENCH 1.5mm
#z903 - ALLEN WRENCH 2.5mm
#z904 - ALLEN WRENCH 2.0mm
#z905 - ALLEN WRENCH 3.0mm


HPI Savage 25 Videos



Savage 25 Engine Tuning part 1

Savage 25 Engine Tuning part 2
