I know the Nitro Start S25 has 25 casted in the block. How about the F4.1 and F4.6? Thanks
-
Ask questions. Share your HPI Savage knowledge. Register TODAY!
how to tell the difference between the F4.1 and F4.6
- Thread starter blown68ssrs
- Start date
This site may earn a commission from merchant affiliate
links, including eBay, Amazon, and others.
links, including eBay, Amazon, and others.
- Messages
- 4,790
V 1 4.6
V2 4.6blown68ssrs
Active Member
- Messages
- 110
- Thread starter
- #3
By the looks of it, there's no way to tell from the outside.
- Messages
- 4,790
some of the other guys can tell which is which just by looking. I am kinda new to the savage platform myself. and just know there were several iterations of the
in all versions of the truck.....
I do know the 4.6 v2 is a totally different block, crank, piston and sleeve and all, the head is different and sits down lower on the block to lower the cg of the truck some.... and the case is black in color vs the 4.1 being natural colored alloy
Pictures just don't illustrate the differences well in most cases to me, maybe is my old
in all versions of the truck.....I do know the 4.6 v2 is a totally different block, crank, piston and sleeve and all, the head is different and sits down lower on the block to lower the cg of the truck some.... and the case is black in color vs the 4.1 being natural colored alloy
Pictures just don't illustrate the differences well in most cases to me, maybe is my old
blown68ssrs
Active Member
- Messages
- 110
- Thread starter
- #5
Reason I asked is, I bought an used "f4.6" and the truck goes the same as my S-25. Not big deal. Only paid 40 for it and it came with the roto start and backplate.
I will put my S-25 back it and take a grinder to it to open up the ports.
I will put my S-25 back it and take a grinder to it to open up the ports.
blown68ssrs
Active Member
- Messages
- 110
- Thread starter
- #6
Just noticed the difference in the number of fins in the head 11 vs 12.
My new used engine is a 4.1. No wonder it goes just like my S-25.
My new used engine is a 4.1. No wonder it goes just like my S-25.
bifftit
Well-Known Member
- Messages
- 321
- Location
- North dakota
F4.1 went into savages that sold in Europe
on the 4.1 if you look under the head at those fins that cover the sleeve area.you will notice they are bigger than any of the other hpi engines(.25, F4.6 K 4.6).
ALSO, the 4.1 usss a .25 sized head and head button and it uses a .25 crank and bearings will not accept 4.6 bearings or crank.but a .25 crank will work
I have not fired my rebuilt f4.1 yet and probably wont, hell, it may not even run...lol. when i recieved it, i had a very difficult time identifying it but i did manage to do so with alot of research
on the 4.1 if you look under the head at those fins that cover the sleeve area.you will notice they are bigger than any of the other hpi engines(.25, F4.6 K 4.6).
ALSO, the 4.1 usss a .25 sized head and head button and it uses a .25 crank and bearings will not accept 4.6 bearings or crank.but a .25 crank will work
I have not fired my rebuilt f4.1 yet and probably wont, hell, it may not even run...lol. when i recieved it, i had a very difficult time identifying it but i did manage to do so with alot of research
J.LO's SAVAGE X
Well-Known Member
- Messages
- 600
- Location
- eudora kansas
also f4.1 has a raw aluminum unpainted block
J.LO's SAVAGE X
Well-Known Member
- Messages
- 600
- Location
- eudora kansas
and if your going to grind on the ports , run 3 shims, if it has 4 or more shims, I do that to all my hpi big blocks. more compression, power!
